LOS ANGELES METRO LIGHT RAIL
Metro Map at Del Mar

Metro uses what is worldwide a common kind of stylized and geographically highly distorted map to depict the system's rail network.  This map also shows some other key links.

This 2006 version of the map depicts the Gold Line extension to East L.A. in its "under construction" status.  It also shows the Orange Line, an express bus route utilizing mostly-reserved right of way in the San Fernando Valley.  Both subway routes appear under "Red Line" coloring, before the Purple Line designation came about.
